The 17,000-square foot arena floor is ideal for large affairs, including galas, and dinners for 600-800 people.
Seating Capacities
180° End Stage Setup Capacity: 11,567
220° End Stage Setup Capacity: 12,776
240° End Stage Setup Capacity: 13,382
270° End Stage Setup Capacity: 13,912
360° End Stage Setup Capacity: 14,220 (floor capacity not included)
Load In/Load Out
Loading docks with dock plates: 4
Elephant door for tall ground level access to the backstage: 1
Push to the arena floor: 130 ft
Elevators
Freight Elevator: 8,000lbs, 7’x11’
VIP Elevator: 3,000lbs, 6’8”x4’9”
Handicap Elevator: 3,000lbs, 6’8”x4’9”
Stage Equipment
Type: Stage Right - Portable/ Aluminum Construction
Stairs: 4 Detachable Rolling Sets
Risers: Stage Right - Adjustable from 1’ to 6’
Extras: Stage Skirt, Safety Rails, Toe Rails, Cable Ramps
Barricades: Stage Right - 20 Sections - 4’ in length each
Bike Rack: 60 Sections - 8’ in length each
Backstage Facilities
Men’s General Locker Room: 7’x44’
Women’s General Locker Room: 7’x44’
Production Office: 10’x16’
Production Workroom: 16’x16’
Loading Dock (Five Bay Doors): 66’x54’
Green Room/Dining: 26’x51’
Pantry: 16’x21’
Locker Room 1: 26’x13’
Locker Room 1 Bathroom/Shower: 26’x12.5’
Locker Room 2: 26’x13’
Locker Room 2 Bathroom/Shower: 26’x12.5’
Locker Room 3 Front Room: 14’x14’
Locker Room 3 Back Room: 28’x12’
Locker Room 3 Bathroom/Shower: 26’x12.5’
Locker Room 3 Side Room: 7.5’x16.5’
Locker Room 3 Side Room: 6’x16.5’
Locker Room 4: 17’x31’
Locker Room 4 Bathroom/Shower: 18’x16’
Star Room A: 8.5’x8.5’
Star Room B: 10.5’x12’
Star Room C: 10.5’x12’
Star Room D: 8.5’x8.5’
House Sound
EAW Systems Multi Point System
40 Channel Soundcraft Console (Portable)
16 Channel Mackie (Portable)
Press Audio with 32 Channel Distribution Package - Audio Booth
32 Channel Midas Console
Yamaha EQs / DBX Compression
Yamaha Floor Fill
Yamaha Monitors
Shure Wireless Microphones
Clear-Com
House Lighting
Computer controlled LED house lighting
Foot Candles - 180
Spotlights - 8 Lycian 1290 XLT – 2k Xenon
Stage Power
End Stage Set Up:
All power 120/208 Voltage, 3 Phase, 5 Wire
Stage Right Power (approx. 60’ off DSE):
Two 400 AMP Disconnects
One 200 AMP Disconnects
One 100 AMP Disconnects
Stage Left Power (approx. 60’ off DSE):
Two 400 AMP Disconnects
Three 200 AMP Disconnects -2 Isolated
One 50 AMP Dryer power
Loading Dock Power:
Five 200 AMP Disconnects
Stage right and the loading dock are run off of the same power
